INTERIOR DRAINTILE SYSTEMS

Experienced Interior Drain Tile Technicians in Woodbury, MN

POLYDRAIN – DRAIN TILE SYSTEM

PolyDrain uses air-gap technology to significantly increase water drainage and promote replacement of the foundation floor at the original thickness. PolyDrain maintains a 5/8 air gap between the footer and the replacement slab. PolyDrain is laid directly onto the footer and extends over the drain system. Eliminating gravel on the footer boosts water flow by removing resistance.

By extending PolyDrain up the wall, the weep holes are protected and any moisture from the foundation wall is channeled into the drainage system. PolyDrain is made from Ultra-High Molecular Weight (UHMW) thermoplastic, and can be bent and folded as needed with no cracking.

ADVANTAGES

  • Increases water flow into the drain system
  • Eliminates sweating of concrete
  • Allows thicker replacement floor
  • Excellent for thin floors and high footers
  • Heavy duty commercial grade material
PolyDrain (PDF)

Prior to beginning any waterproofing method or installation, Rite-Way Waterproofing takes necessary protective measures, including:

  • Covering carpeted floors in the immediate work area with tarps
  • Covering all articles in the basement with plastic sheeting
  • Sealing heated air duct openings in the basement to prevent dust from spreading throughout the home
  • If necessary, laying planking over the lawn to prevent damage
  • Transferring all tools, crushed rock, cement, and debris through basement windows, eliminating numerous trips on the stairs and throughout the home

When you need interior drain tile services in Woodbury, MN, let the team at Rite-Way Waterproofing put your mind at ease with our personalized and dedicated services. Our interior drain tile technicians can quickly get to the root cause of your drain tile issues and provide you with a helpful service that ensures the health and safety of your commercial or residential property in Woodbury, MN.


We can offer your flexible scheduling services and affordable rates so that you can maximize the efficiency of your property. We understand that drain tile issues can pose small and large dangers for your property that can build over time.


That's why our team is excited to provide you with a memorable customer service experience that you can count on. If you are ready to experience the difference that Rite-Way Waterproofing can provide, reach out to our friendly team today through our helpful contact page. We look forward to connecting with you soon and providing you with interior drain tile services in Woodbury, MN.


THE RITE-WAY GUARANTEE

At Rite-Way Waterproofing we can provide a list of over 300,000 satisfied customers who have enjoyed a dry basement after having us install the Rite-Way System.

The system we are installing today is virtually the same as we installed 57 years ago. We do not offer any "new or upgraded systems". If our system didn't function properly the first time, our company wouldn't function either.

We operate with only company employees who are fully insured and trained by our long-term personnel. When you opt to work with Rite-Way Waterproofing that's exactly who you will be working with – we do not subcontract any portion of our installation. Our firm has provided expert waterproofing service since 1965 and we are proud to declare that our staff has over 100 years of combined waterproofing experience.

Warranty Information — Lino Lakes, MN — Rite-Way Waterproofing

Information courtesy Richtech Industries – richtechindustries.com


XYPEX CONCENTRATE WATERPROOFING

Xypex® is a unique chemical treatment for the waterproofing, protection and repair of concrete. When mixed with water, this light grey powder is applied as a cementitious slurry coat to above-grade or below-grade concrete, either as a single coat or as the first of a two-coat application. It is also mixed in Dry-Pac form for sealing strips at construction joints, or for the repairing of cracks, faulty construction joints and honeycombs. Xypex prevents the penetration of water and other liquids from any direction by causing a catalytic reaction that produces a non-soluble crystalline formation within the pores and capillary tracts of concrete and cement-based materials.

ADVANTAGES

  • Resists extreme hydrostatic (fluid-based) pressure
  • Becomes an integral part of the substrate (wall, foundation, block, etc.)
  • Can seal hairline cracks up to 0.4 mm
  • Allows concrete to breathe
  • Highly resistant to aggressive chemicals
  • Non-toxic
  • Does not require a dry surface for application
  • Cannot puncture, tear or come apart at the seams
  • No costly surface priming or leveling prior to application
  • Does not require sealing, lapping or finishing of seams at corners, edges or between membranes
  • Can be applied to the positive or the negative side of a concrete surface
  • Does not require protection during backfilling or during placement of steel, wire mesh or other materials
  • Less costly to apply than most other methods
  • Not subject to deterioration
  • Permanent
  • Does NOT work for hollow core block foundations
Xypex® Concentrate (PDF)

Information courtesy Xypex® Chemical Corporation – xypex.com

EXPOSED FOOTINGS

  1. Break trenches approx. 12"-16"wide.
  2. Dig trenches approx. 1O" -12"deep from top of floor & "form" footing under block at 45-degree angle.
  3. Line trench with Filter Fabric (approx. 20"wide) anchoring to bottom of footing.
  4. Install 24"wide piece of Polydrain over Geo Fabric, using extra Fabric on drain board to overlap trench filter.
  5. Install Draintile & River rock.
  6. Cover rock with Polydrain.
  7. Replace concrete with same thickness as original.

NO FOOTING

  1. Break trenches approx. 16" wide.
  2. Dig trenches approx. 12" deep from top of floor & "form" footing under block at 45-degree angle.
  3. Line trench with Filter Fabric (approx. 20" wide) anchoring to bottom of block.
  4. Install 12 " wide piece of drain board over Filter Fabric, using extra Fabric on drain board to overlap trench filter.
  5. Install tile & rock as diagrammed.
  6. Cover rock with poly.
  7. Replace concrete with same thickness as original

WOOD FOUNDATIONS

Please call for more information.

POURED WALL CRACK INJECTIONS

Coming soon...
